Super 4 way diversity, indoor/outdoor antenna
Features
SPECIFICATIONS:
Channels Received VHF Channels 1-12,UHF ?Channels 13-62
Supply Voltage DC 13.2V(10.8-15.8V) Negative Earth
Consumption Current 70mA(max 130mA)
Power Supply Fuse 1.5A
Booster Gain 6-10dB(VHF Band),4-8dB(UHF ?Band)
Antenna Terminals 3.5 Monoplug(75O)×4
Cable Length 4.8m
Weight: Outdoor Antenna: Approx .50g
Indoor Antenna, Power Supply Unit: Approx 420g
Notes:
The is an antenna for mounting on the rear window. This product cannot be mounted on locations without glass.
To utilize the full power of the most effectively, read the enclosed operating instructions carefully before using this product.
1 MAIN FEATURES:
The is a 4-way diversity antenna comp rising an indoor 3-way antenna (including a signal booster) and an outdoor 1-way antenna.
Connect the LCD Screen Car TV (sold separately) to from a complete diversity system. This system instantly adjusts to the optimum angle for signal reception, thereby reducing disturbance and flickering of the image.
Because the is mounted on the rear window, it fits on all cars, no matter what type or shape. The outdoor antenna is connected via the indoor antenna power supply unit. This means that all the wiring can be performed inside the car, and the antenna is easy to mount.
|
